EF 50mm f/1.4 USM

EF 50mm f/1.4 USM

EF 50mm f/1.4 USM

 53,000.00

The ultimate mixture of versatility and image quality

Standard lens offering superb quality and portability. 2 high-refraction lens elements and Gaussian optics eliminate astigmatism and suppress astigmatic difference. With its fast maximum aperture and rapid focusing system, the compact, high performance EF 50mm f/1.4 USM standard lens can be relied on for obtaining crisp images and superb performance in any field of photography.

micro-usm full-time-manual-focusing_b

Highlights

  • Fast f/1.4 aperture
  • Standard 46° angle of view
  • USM focus motor with full-time manual focus override
  • 45cm closest focusing distance
  • Aspherical lens element
  • 58mm filter size


360-view icon

Out of stock

SKU: Prod001-3-1-1-1-2-1-1-1-1-1-2-1-1-1 Categories: ,

Overview

Standard lens featuring superb quality and portability. Two high-refraction lens elements and new Gaussian optics eliminate astigmatism and suppress astigmatic difference. Crisp images with little flare are obtained even at the maximum aperture.

Versatile, compact standard-lens design

Gaussian optics, combined with two high-refraction lens elements allow photographers working in all fields to capture crisp, clean images, even wide open at f/1.4. The lens is ideal for photographing landscapes and travel scenes as well as portraits and reportage.

Ultrasonic focusing

A ultrasonic motor drives autofocus extremely quickly, and in near silence. Excellent holding torque ensures the point of focus is reached accurately, without overshooting. Furthermore, full-time manual override is available, making it possible to adjust focus without leaving AF mode.

Smooth background blur

A virtually circular aperture diaphragm gives out of focus regions a softer, more uniform feel. Sharp foreground objects stand out against a smooth blurred background.

Super Spectra coating

Super Spectra coatings ensure accurate colour balance and enhance contrast. They also reduce flare and ghosting – a common problem caused by light bouncing off a camera’s sensor.

  • EF Mount Lens
  • F/1.4
  • Seven Element Optical Formula
  • Gaussian Optics Eliminate Astigmatism
  • Micro Ultrasonic Autofocus Motor
  • Manual Focus Override
  • Minimum Focusing Distance: 17.8″
  • Filter Thread Diameter: 58mm

ef_50_14sample









Features

Ring USM, Micro USM, Nano USM

Enables silent and high-speed focusing

USM (Ultrasonic Motor) was first put into practical application in the world by Canon. USM drives the lens by transforming ultrasonic vibrations into rotation energy. Not only does it consume little power, it has high efficiency, torque and response, enabling high-speed focusing with almost no operating sound emitted.

There are three types of USM . The round-shaped Ring USM is simple in structure, and is best suited for use in a circular lens tube. It is especially useful for driving lenses such as large-diameter or super telephoto ones due to its high torque, and it also allows for full-time manual focusing. Meanwhile, the Micro USM can be employed on many types of lenses because it is low in cost and not subject to restrictions on the lens diameter. In 2002, Canon contributed further to the downsizing of lenses with the development of the Micro USM II, which is about half the size and weight of the Micro USM . And in 2016, Canon introduced Nano USM, which not only realizes a high speed AF that rivals that achieved by Ring USM, but also is able to operate quietly and seamlessly. It’s not an exaggeration to describe Nano USM as the most ideal motor for normal-use lenses that are meant to handle both still photography and movie shooting.

 Rung USM

ring-micro-usm2

Micor USM (Left), Micro USM II (Right)

ring-micro-usm1

Nano USM—The thin and tiny USM motor that achieves fast and smooth AF

Thin and compact, this USM, the latest to be developed by Canon, made its debut in 2016 on the EF-S18-135mm f/3.5-5.6mm IS USM. Computer chip-shaped (a factor that allows a more compact lens design) with power sources in the form of transducers, it connects directly to the AF actuating mechanism. It possesses a speediness and responsiveness that rivals that of the Ring USM, combined with a control that equals that of STM (lead screw-type). Its main benefit lies in enabling quiet, smooth AF operation in compactly-sized lenses such as standard zoom lenses. Also very suitable for movie-shooting, its high speed AF is able to handle scenes with subjects that are moving at a fast speed as well as those with unpredictable movements.

ring-micro-usm3

The Nano USM is shaped like a computer chip, and has 2 transducers in its center.

Ef 16-35mm f2.8L III USM Cross Section Ef 16-35mm f2.8L III USM Cross Section 2

A cross section of the EF-S18-135mm f/3.5-5.6 IS USM, released in 2016 and the first lens to carry the Nano USM. Moving along the top of the slider, the Nano USM directly drives the main AF power source. As this motor not only allows for fast and smooth AF but is also small in size, it makes it possible for the lens that utilize it to be around the same size as lenses with STM.





Full-time Manual Focusing

Enables MF immediately after AF

Many of Canon’s EF lenses are equipped with “full-time manual focusing”, which allows manual focus right after auto focus is complete, just by turning the focusing ring and without the need to switch to MF mode. All Ring USM and STM lenses support full-time manual focusing.

full-time-manual-focusing1

Versatile, compact standard-lens design

Gaussian optics, combined with two high-refraction lens elements allow photographers working in all fields to capture crisp, clean images, even wide open at f/1.4. The lens is ideal for photographing landscapes and travel scenes as well as portraits and reportage



Smooth background blur

A virtually circular aperture diaphragm gives out of focus regions a softer, more uniform feel. Sharp foreground objects stand out against a smooth blurred background.

Super Spectra coating

Super Spectra coatings ensure accurate colour balance and enhance contrast. They also reduce flare and ghosting – a common problem caused by light bouncing off a camera’s sensor.



Specifications

PHYSICAL SPECIFICATIONS

Specification Details
PRODUCT WEIGHT INPUT-1 290 g
FILTER DIAMETER (MM) 58
MAXIMUM DIAMETER X LENGTH (MM) 73.8 x 50.5

OPTICAL CHARACTERISTICS

Specification Details
AF ACTUATOR Micro USM
LENS CONSTRUCTION (ELEMENTS/GROUPS) 7/6
MINIMUM APERTURE 22
MAGNIFICATION WITH EXTENSION TUBE EF12 II 0.39-0.24
MAGNIFICATION WITH EXTENSION TUBE EF25 II 0.68-0.53
ANGLE OF VIEW 40º, 27º,46º (horizontal, vertical, diagonal)
MAGNIFICATION 0.15

ACCESSORIES

Specification Details
EXTENDER COMPATIBLITY  Not Compatible



Reviews

There are no reviews yet.

Be the first to review “EF 50mm f/1.4 USM”

Your email address will not be published. Required fields are marked *

QR Code

QR Code

You may also like…

You may be interested in…

Search or select product to compare

EF-S 18-55mm f/3.5-5.6 III

EF 24-105mm f/4L IS II USM

EF 500mm f/4L IS II USM Lens

EF 70–300mm f/4–5.6 IS USM

EF 50mm f/1.4 USM

Price:53000₨
  • Mount : EF

  • Aperture : f/1.4

  • Lens Type : Fixed/Prime Lens

  • Category : Standard & Medium Telephoto

  • Focal Length Range : 50mm

  • Photography Genre : Portrait

  • Technology : USM

  • Dust/Moisture resistance : No

  • Weight : 290 g

  • Luxury Lens : No

  • IS System : No

  • Lens Construction (Elements/Groups) : 7 elements in 6 groups

  • Filter Diameter (mm) : 58

  • Closest Focusing Distance (m) : 0.45

  • Length (mm) : 50.5
